Max. drilling dia.(mm)

25

32

35

35

50

80

Distance from spindle center to generating line of column(mm)



390~870

300~1000

300~1300

350~1600

500~2500

Distance from spindle nose to surface of base worktable(mm)

65~865

50~850

250~1020

320~1020mm

320~1220mm

550~2000

Distance of spindle horizontal movement

500

500

700

1000

1250

2000

Radial swing angle

360°

360°

±180°

±180°

±180°



Spindle taper(Morse)

MT3

MT3

MT4

MT.4

MT5

MT6

Spindle speed & steps

173~960r/min

4 Steps

173~960r/min

4 Steps

50~2350r/min

12 Steps

50~2350r/min

12 Steps

25~2000r/min

16 Steps

16~1250 r/min，16 Steps

Feed rate & steps

0.1~0.4mm/r

4 Steps

-

0.13~0.54mm/r

4 Steps

0.13~0.54mm/r

4 Steps

0.04~3.2mm/r

16 Steps

0.04~3.2 mm/r

16 Steps

Spindle travel(mm)

135

120

250

250

315

450

Main motor power（kw）

1.5

1.5

3

3

4

7.5

Weight(kg)

900

850

1600

1780

3500

-

Working area of base(mm)

635×430

635×430

1050×550

1350×550

1590×840

-

Working area of table(mm)





450×450

450×450

500×630

800×1000

Overal dimensions (LxWxH)(mm)

1760×570×1900

1760×570×1900

1805×800×2320

1805×800×2320

2500×1070×2840

-
