Max. drilling dia.(mm)

25

32

35

40

50

63

80

100

Max. feeding resistance(N)

9000

9000

16000

16000

16000

30000

30000

45000

Max. allowed spindle torque(N.m)

160

160

400

350

350

800

800

1150

Spindle taper(Morse)

MT3

MT4

MT4

MT4

MT5

MT5

MT6

MT6

Distance from spindle center to guide (mm)

280

280

300

335

335

375

375

480

Spindle travel(mm)

200

200

225

250

250

250

250

310

Spindle box travel(mm)

200

200

200

200

200

250

250

300

Spindle speed steps

9

9

9

12

9

9

9

6

Spindle speed (rpm)

50~2000

50~2000

68~1100

31.5~1400

45~850

40~570

40~570

26~320

Feed steps

9

9

11

9

9

6

6

6

Feed rate(mm/rpm)

0.056~1.80

0.056~1.80

0.11~1.60

0.056~1.80

0.056~1.80

0.1~0.78

0.1~0.78

0.096~0.717

Table travel(mm)

310

310

325

300

300

300

300

300

Working area of table(mm)

400×550

400×550

450×500

480×560

480×560

650×550

650×550

760×650

Max. distance from spindle nose to surface of worktable(mm)

710

710

750

750

750

800

800

850

Max. distance from spindle nose to surface of base worktable(mm)

-

-

-

-

-

1250

1250

-

Main motor power(kw)

2.2

2.2

4

3

4

5.5

5.5

7.5

Flow of cooling pump(l/m)

25

25

25

25

25

25

25

25

Overal dimensions (LxWxH)

962×847×2300

962×847×2300

1280×842×2590

1040×905×2530

1040×905×2535

965×1452×2787

965×1452×2787

1465×970×2317

Net weight (kg)

950

950

1600

1250

1250

2500

2500

3500
