Max. dirlling capacity(mm)

25

25 (1”)

31.5mm (1.24”)

32

35 (1.38”)

40 (1.57”)

Max. tapping capacity

-

M20 (0.79”)

M24 (0.94”)

M27 (1.06”)

Distance from axis of spindle to generating line of column(mm)

240

240

315

280

350

350

Max. distance from spindle nose to working surface of works table(mm)

830

830

685

760

640

635

Max. distance from spindle nose to working surface of base plate(mm)

-

1200

1195

1270

1230

1225

Max. travel of spindle(mm)

110

135

135/135/160

140

160

180

Max. travel of work table support arm(mm)

600

480

580

460

600

450

Swivel angle of spindle box, worktable

-

-

-

±45°

-

-

Effective working area of worktable(mm)

Φ350

321x350 or Φ350

400x350

400x350

400x450

400x450

Spindle bore taper (Morse)

MT3

MT3,MT4

MT4



Spindle Speed steps

12

stepless regulating

Spindle speed (rpm)

125~2880

80~2800

80~2800/

80~2800/

75~2700

80~2800

64-2280

50-1800

Spindle feed steps



3(only A type)

3(only A and B)

3

3

4

Spindle feed range (mm/r)



0.12~0.32(only A type)

0.12~0.32(only A and B)

0.12~ 0.32

0.12~0.32

0.1~0.4

Spindle feed method

manual

Manual/

mechanic

Manual/

mechanical/

mechanical

mechanical

electromagnetism

electromagnetism

Motor

Power (KW)

0.85/1.1

0.85/1.1,

0.85/1.1,

1/1.5

0.85/1.1

1.5/2.2

2/2.4

Voltage (V)

220, 380, 400, 420, 440

Overal dimensions (LxWxH)

485x640x1750

605x510x1780

800x510x1780

910x515x1800

910x515x1800

910x515x2144

870x550x1820

1080x600x1950

1080x600x2305

1030x600x1950

Net weight / Gross weight (kg)

270/309

313/357

325/369

368/416

380/428

390/438

440/488

560/615

570/625

580/635

Package (LxWxH) (mm)

760x620x1860

880x640x1900

800x640x1900

950x640x2010

950x640x2010

950x640x2350

950x640x2010

1120x690x2130

1120x690x2130

20″ Container loading (sets)

18

20

16
