Feature:

Precision ground

CE-conformity; magnetoelectrical brake can be amounted

Safety torque limiting device for lead screw

Safety overload clutch for feedrod

Rapid traverse (optional)

Main spindle supported at 2 points with precision taper roller bearings

STANDARD ACCESSORIES

3-jaw chuck 250mm

Driving plate

Center & center sleeve

Oil gun

Wrenches

Operation manual

OPTIONAL  ACCESSORIES

Steady rest

Follower rest

4-jaw chuck 320mm

Face plate

Thread dial

Longitudinal automatic trip

Live center

Quick change toolpost

Taper copy ruler

4-position longitudinal antomatic trip

MODEL		LC6 236	LC6240	LC6245	LC6250	LC6260
CAPACITIES	Max. swing over bed	360mm (14”)	400mm (16”)	450mm (18”)	500mm (20”)	600mm (24”)
	Max. swing over cross slide	185mm (7 1/4”)	225mm (9”)	285mm (11 1/5”)	325mm (13”)	360mm (14”)
	Center distance	1000, 1500, 2000mm
	Max swing over gap	490mm (20”)	530mm (21”)	580mm (23”)	630mm (25”)	730mm (29”)
	Effective length of gap	260mm (10 1/4”)
	Bed width	330mm (13”)
HEADSTOCK	Spindle hole	80mm (2 3/5”)
	Spindle nose	ISO-C8 or ISO-D8
	Spindle taper	Metric 85mm
	Spindle speeds (Number)	24-1600rpm (15 Steps)
FEEDS	Metric threads range (Kinds)	0.5-28mm (66 Kinds)
	Inch threads range (Kinds)	1-56inch (66 Kinds)
	Moudle threads range (Kinds)	0.5-3.5mm (33 Kinds)
	Diametral threads range (Kinds)	8-56D.P (33 Kinds)
	Longitudinal feeds range (Kinds)	0.072-4.038mm/rev (0.0027-0.15 inch/rev) (66 Kinds)
	Cross feeds range (Kinds)	0.036-2.019mm/rev (0.00213-0.075 inch/rev) (66 Kinds)
	Rapid travelling speed of carriage	5m/min (16.4 ft/min)
	Leadscrew size: Diameter Pitch	35mm/6mm or 35mm/1/4”
CARRIAGE	Cross slide travel	300mm (13”)
	Compound rest travel	130mm (5”)
	Cross-section size of toolshank	20 x 20mm	20 x 25mm (1 x 6/8inch)			25x 25mm
TAILSTOCK	Taper of tailstock sleeve	Morse No.5
	Diameter of tailstock sleeve	75mm (23/5”)
	Travel of tailstock sleeve	120mm (43/4”)
MOTOR	Main drive motor	4.0kw or 5.5kw or 7.5kw			7.5kw
	Coolant pump motor	0.125kw
	Rapid traverse motor	0.12kw
Packing Size (L x W x H)
Center distance	1000mm	2420 x 1150 x 1800mm (96 x 46 x 71in.)
	1500mm	2920x 1150 x 1800mm (115 x 46 x 71in.)
	2000mm	3460 x 1150 x 1800mm (137x 46 x 71in.)
	Net Weigh/Gross Weight (Kgs)
Center distance	1000mm	1520/2170kg	1560/2210kg	1580/2230kg	1600/2250kg	1640/2290kg
	1500mm	1750/2390kg	1770/2410kg	1820/2460kg	1830/2470kg	1870/2530kg
	2000mm		2010/2780kg	2050/2800kg	2070/2820kg	2130/2860kg
