Working Surface of Table

mm

300×600(12”×24″)

400×800(16″×32″)

500×1000(20″×40″)

Max.Table Travel

mm

660

920

1140

Max. Cross Travel

mm

370

450

540

Distance from Table Surface to Spindle Center

mm

540

580

590

Max. Table Load

kgs

420

700

700

Tee Slot(Number × Width)

mm

1×14

3×14

3×16

Table Speed

m/min

 5~25

5~25

5~25

Crossfeed Handwheel

mm

 0.02/grad.

5/rev.

0.02/grad.

5/rev.

0.02/grad.

5/rev.

Automatic Crossfeed

mm

0.5~12

0.5~12

0.5~12

Rapid Crossfeed

mm

790,50hz  950,60hz

790,50hz  950,60hz

1250,50hz  1500,60hz

MPG Handwheel feed Rate



×1, ×10, ×100

×1, ×10, ×100

×1, ×10, ×100

Min. Down Feed Rate

mm

0.001

0.001

0.001

Power Head Increment

mm/min

210

210

210

Wheel Size(dia.×width×bore )

mm

355×40×127

 355×40×127

355×40×127

Spindle Speed

rpm

1450,50hz  1740,60hz

1450,50hz  1740,60hz

1450,50hz  1740,60hz

Spindle Motor

kw

4.0

5.5

5.5

Vertical Motor

nm

3.57

3.57

2.6

Hydraulic Motor

kw

1.5

2.2

2.2

Dust Collection Motor

w

550

550

550

Coolant Motor

w

90

90

90

Cross Feed Motor

kw

90

90

370

Floor Space

mm

2600×2500

3600×2600

4445×2200
