Working Surface of Table

mm

150×450

200×460

150×450

(5.9″×17.7″)

160×460

(6″×18”)

200×460

(8″×18”)

255×510

(10”×20”)

Max.Table Travel

mm

 483

540

483

495

 510

620

Max. Cross Travel

mm

178

280

178

220

250

280

Distance from Table Surface to Spindle Center

mm

361

470

361

530

530

535

Max. Table Load

kgs

100

100

100

120

120

120

Tee Slot(Number × Width)

mm

1×14

1×14

1×14

 1×14

1×14

1×14

Table Speed

m/min

Manual

Manual

Manual

Manual

Manual

Manual

Cross feed Handwheel

mm

0.01/grad.

2.5/rev.

0.02/grad.

4/rev.

0.01/grad.

2.5/rev.

0.02/grad.

5/rev.

0.02/grad.

5/rev.

0.02/grad.

5/rev.

Vertical feed Handwheel

mm

0.005/grad.

1.25/rev.

0.01/grad.

2 /rev.

0.005/grad.

1.25/rev.

0.01/grad.

2 /rev.

0.01/grad.

2 /rev.

0.01/grad.

2 /rev.

Wheel Size(dia.×width×bore )

mm

180×13×32/31.75

205×20×32/31.75

180×13×32/31.75

200×25×32/31.75

200×25×32/31.75

200×25×32/31.75

Spindle Speed

rpm

2850,50hz 3420,60hz

2850,50hz 3420,60hz

2850,50hz 3420,60hz

2850,50hz 3420,60hz

2850,50hz 3420,60hz

2850,50hz 3420,60hz

Spindle Motor

kw

1.1

1.5

1.1

1.5

1.5

2.2

Dust Collection Motor

w

 550

550

550

550

550

550

Coolant Motor

w

 40

90

90

90

90

90

Floor Space

mm

 1900×1300

 1800×1400

1900×1300

1900×1900

1900×1900

1900×2300
